Band Clamp Kit
Band Clamp Kit General Information
"Band Clamp Kit" used for ventilation purposes, manufactured by a company named TORK. The kit includes a 3-meter unperforated roll band and 8 clips, available in two sizes, 9mm and 12mm in band width, with corresponding band thicknesses of 0.6mm and 0.8mm. The screws included are either 6mm or 7.5mm in size. The materials listed for these components are W1 Aluzinc Band and clip cover, with RoHS compliant zinc plated screws, and W2 430 SS Band sheet with galvanized clip cover and RoHS compatible screws. The packaging appears to be a clear plastic blister pack with the roll band and clips visible. Additional information such as the product codes for the different sizes is provided along with the company’s website, emphasizing the product's quality types and materials used. This kit seems suitable for securing ductwork or other components in a ventilation system.
Band Clamp Kit Application Areas
- Ventilation and air conditioning systems
- Exhaust fan systems
- Large diameter flexible hoses
Band Clamp Kit Producible Quality Types
Product Code | Description | Band Widthi | Band Thickness | Screw |
MRK009W1-0308-01 | 3 mt. W1 unperforated Roll Band and 8 clips | 9 | 0,6 | 6 mm |
MRK009W2-0308-01 | 3 mt. W2 unperforated Roll Band and 8 clips | 9 | 0,6 | 6 mm |
MRK012W1-0308-01 | 3 mt. W1 unperforated Roll Band and 8 clips | 12 | 0,8 | 7,5 mm |
MRK012W2-0308-01 | 3 mt. W2 unperforated Roll Band and 8 clips | 12 | 0,8 | 7,5 mm |
Band Clamp Kit Materials
W1 | Aluzinc Band and clip cover, Rohs compliant zinc plated Screw
W2 | 430 SS Band sheet, galvanized clip cover and Rohs compatible Screw
